Stainless Steel Mirror Polished Pipe
, A213 Mirror Stainless Steel Pipe
, 316LN Stainless Steel Pipe
Cold Rolled Stainless Steel Mirror Polished Pipe ASTM A213 316LN Diameter
Characteristic
316LN has corrosion resistance, toughness, ductility, formability, stress corrosion cracking resistance, hardness, etc. These features make it an ideal choice for many applications where metal needs to remain strong yet flexible enough to withstand extreme temperatures or corrosive environments.
Specification
| Ends |
Plain end |
| Color |
silver |
| Delivery time |
within 15 -20 days. |
| Payment Terms |
40% prepayment Balance before lodaing. |
| Shipping Terms |
FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package |
Standard export seaworthy package,or as required. |
Mechanical Properties
316LN ss has a good combination of strength and ductility with excellent stress corrosion cracking resistance in both low temperatures (–50°C) and high temperatures (450°C). It also has better formability than 304 or 309 grades due to its lower carbon content, allowing it to be easily formed into shapes like sheets or pipes without requiring much heat treatment. Its hardness ranges from about 70 HRC up to 75 HRC depending on its composition and the heat treatment process used during manufacturing.
|
Properties
|
Metric
|
Imperial |
| Tensile strength |
515 Mpa
|
74694 psi |
| Yield strength |
205 Mpa |
29732 psi |
| Modulus of elasticity |
190-210 Gpa |
27557-30457 ksi |
| Poisson's ratio |
0.27-0.30 |
0.27-0.30 |
| Elongation at break(in 50 mm) |
60% |
60% |
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
316LN SS pipe Usage
316LN SS is often used in applications that require superior corrosion resistance, such as food processing equipment, chemical plants, medical instruments and marine environments like shipbuilding or offshore platforms.It’s also commonly used in automotive exhaust systems, paper mills, industrial machinery parts and heat exchangers.
Physical Properties
316LN has a high corrosion resistance due to its high chromium and nickel content. It also has a higher toughness than regular stainless steel alloys thanks to its nitrogen content which helps improve its tensile strength and yield strength. Its melting point is around 1370°C (2500°F).
| Specific Heat(0-100℃) |
485 |
J.kg-1.°K-1 |
| Thermal Conductivity |
16.3 |
W.m-1.°K-1 |
| Thermal Expansion |
16.5 |
mm/m/℃ |
| Modulus Elasticity |
200 |
GPa |
| Electrical Resistivity |
7.4 |
μohm/cm |
| Density |
7.99 |
g/cm3 |
Chemical Composition Of 316LN
Grade 316LN is a low-carbon version of 316 with an addition of nitrogen. It contains 16-18% chromium,10-14% nickel, 2-3% molybdenum, 2% manganese, 1% silicon, 0.03% carbon, 0.045% phosphorus,0.03% sulfur and 0.10-0.30% nitrogen.
| Grade |
Cr |
Ni |
Mn |
Si |
C |
P |
S |
Fe |
Mo |
N |
| 316LN |
16-18 |
10.0-14.0 |
2 |
1.00 |
0.03 |
0.045 |
0.03 |
Balance |
2.0-3.0 |
0.10-0.30 |
Package Process
1.With plastic cap to protect both ends
2.Weaving bag wrapped outside the pipe
3.Then pack into wooden case.
